I have a bizarre problem with programming my Pronto 7000 remote to turn OFF my JVC DLA-HD350 projector. The Standby/Off button of the JVCs own remote must be pressed twice to actually turn off the unit (there is a confirmation screen).

As for all other codes of all other devices, I learned the IR codes for the JVC remote into my Pronto. All work great except this OFF function. Despite sending the learned code twice and a delay between the two ranging from 0.2 to 4 seconds, the projector will not respond to the SECOND code. It correctly reads the first since i see the confirmation screen, but ignores the second.

I have tried the discreet ON/OFF codes found on this site and even found a JVC document that offered a code (that they say to simply send twice). NO luck.

Has anyone else seen this problem??

Thanks for any and all help.

Tom Stanley

 what happens if you try a different command between the off codes?

for instance

off
arrow up
off

What does the 'confirmation' screen say?
Should the second command be 'yes' or 'accept'??

Also try increasing the duration of the second Off code.

You can also try this,

Off
0000 006D 0012 0011 0141 00A0 0014 003C 0014 003C 0014 0014 0014 0014 0014 003C 0014 003C 0014 003C 0014 0014 0014 0014 0014 003C 0014 003C 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0155 0014 003C 0014 003C 0014 0014 0014 0014 0014 003C 0014 003C 0014 003C 0014 0014 0014 0014 0014 003C 0014 003C 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0336


Cheers
Jason

Jasonvp!

You are the man! Where did that discrete code come from? Works great sent only once at standard (0.25sec) duration.

Thank you very much.

Tom

I have special powers :)



Gee whiz!...he looks just like me. :)

cool!  that is exactly how I pictured you!  :p

Thanks for the new Power Off command. I am going to try it on the next RS1X I do and see if it works.

As far as the OP is concerned, the JVC's have a built in sensor that will not allow you turn it off for a set time after turn on. It drove me crazy trying to figure out why it didn't work consistently. If you let the unit stay on for a few minutes, the Standby pressed twice works every time.

Thanks for the new Power Off command. I am going to try it on the next RS1X I do and see if it works.

As far as the OP is concerned, the JVC's have a built in sensor that will not allow you turn it off for a set time after turn on. It drove me crazy trying to figure out why it didn't work consistently. If you let the unit stay on for a few minutes, the Standby pressed twice works everytime.

This works as direct off (no double press) on my RS35:

0000 006D 0001 0011 0141 00A0 0014 003C 0014 003C 0014 0014 0014 0014 0014 003C 0014 003C 0014 003C 0014 0014 0014 0014 0014 003C 0014 003C 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0014 0336

The 2 documents available here provide a lot of discrete IR codes for the current generation JVC projectors:
[Link: uk.jvc-service.net]
